Delivery of 6 sets of Guangxi high pressure roots blowers XQSSR15030KW6

Source: Roots blower manufacturer Published on: May 13, 2021 Hits:

Delivery of 6 sets of Guangxi High Pressure Roots Blower Xinqianshun XQSSR150 30KW
Xinqianshun XQSSR125 15KW 4 sets

Shipped 6 sets of Guangxi high pressure roots blower XQSSR15030KWs (Figure 1)

Structural composition of high-pressure roots blower:
High pressure Roots blower is composed of four parts, namely, casing, wallboard, impeller, inlet and outlet muffler.

Casing: mainly used to support wallboard, impeller, muffler and fixation.
Wall plate: mainly used to connect the casing and the impeller, support the rotation of the impeller, and play the role of end sealing
Impeller: It is the rotating part of the high-pressure Roots blower, which is divided into two leaves and three leaves. Now, the three leaf blower has gradually replaced the two leaf Roots blower because of its advantages such as less air pulsation, less noise and smooth operation than the two leaf blower.

Muffler: used to reduce the noise caused by air flow pulsation at the inlet and outlet of high-pressure roots blower

Shipped 6 sets of Guangxi high pressure roots blower XQSSR15030KWs (Figure 2)

The scope of supply of standard accessories of Xinqian Shun high-pressure roots blower: host, motor, pressure gauge, inlet silencer, outlet silencer, elastic joint, gear oil (injected into the fan), safety valve, one-way valve, base, V-belt, belt cover, host pulley, anchor bolt.
Ordering Instructions
When you need to purchase a blower, please tell us the following items in detail:
1. Use of blower: sewage treatment, aquaculture, pneumatic conveying, etc
2. Fan specifications: caliber, required air volume, pressure rise, etc
3. Transmission medium: air, gas, biogas and other corrosive gases
4. Equipment requirements: form, cycle number, voltage, single-phase or three-phase
5. Equipment service conditions: indoor or outdoor, ambient temperature
6. Fan accessories
7. Fan color (with or without specified color
8. Note: the allowable range of specified flow and pressure rise (vacuum degree) is ± 5%

Welcome to purchase our company's fans and put forward valuable suggestions
